High Purity Centrifugal Pump, Stainless Steel Motor Design

Reference: SV-18S-KS
Inlet & Outlet Sizes: 1 1/2"-3" (DN40-DN80)
End connections: butt-weld, tri-clamp, thread, flange
Body Material: AISI 304 (1.4301), AISI 316L (1.4404)
Mechanisal Seal: single seal (standard), double mechanical seal (option), SIC/C, SIC/SIC
Power Supply: 1.5KW-30KW
Voltage: AC110V, 220-240V, 360-400V, 420-460V, 630-690V, 50/60Hz
Maximum lift head: 70M
Maximum flow: 150m³/h
Maximum temperature: 130℃/266°F, (30min CIP/SIP)
Surface treatment: Ra 16 ~ 32µin (0.4 ~ 0.8µm), Ra 32µin as default.
Drain ports options: vertical, horizontal, incline direction
INQUIRY

APPLICATION

SV-18S-KS series High Purity Centrifugal Pumpp, is whole stainless steel made including the motor. It is high clean exterior and interior designed, with online high-pressure water rinse available to IP67 or IP69 rating.

The pump is very suitable for clean workshop and high clean required workplace, such as biological pharmaceutical, food and beverage, winery, fine chemical industries, etc.

TECHNICAL DATA

Inlet & Outlet Sizes 1 1/2″-3″ (DN40-DN80)
End Connections butt-weld, tri-clamp, thread, flange
Body Material AISI 304 (1.4301), AISI 316L (1.4404)
Mechanisal Seal single seal (standard), double mechanical seal (option), SIC/C, SIC/SIC
Power Supply 1.5KW-30KW
Voltage AC110V, 220-240V, 360-400V, 420-460V, 630-690V, 50/60Hz
Maximum lift head 70M
Maximum flow 150m³/h
Maximum temperature 130℃/266°F, (30min CIP/SIP)
Internal Finish Ra 16 ~ 32µin (0.4 ~ 0.8µm), Ra 32µin as default.
External Finish Sand blast or mirror polish as request

DESIGN FEATURES

● High-lift, low noise, high flow, no dead ends, high-performance characteristics
● Pure stainless steel design, complied with ASME BPE and EHEDG standards.
● 3A sanitary standards, IEC or NEMA B34 motors, IP55, F-class insulation, 50HZ/60HZ.
● Flushed single or double mechanical seal
● Pressure relief valve available internal or external
● Surface heat jacket; complete heat jacket.
● Horizontal or vertical direction
● With stainless steel base plate & adjustable feet
● Different drives and devices
1) Manual adjustment, continuously variable transmission
2) Variable – frequency motor adjustment
3) Fixed speed output transmission
● Motor utilize the IEC EN IE2, PTC thermistor.

DIMENSIONAL DRAWINGS
